The article provides charts linking spiral and helical cutterheads compatible with various Grizzly jointer and planer models, including Byrd and Grizzly brands in sizes from 6" to 20". It also lists compatible cutterheads for other brands and details the specific replacement inserts needed for each cutterhead size and type, with direct product links for convenience.
To replace or upgrade the cutterhead on your Jointer or Planer with a spiral or helical cutterhead, find your machine model number in the charts below to find the cutterheads that will fit your machine. We've linked the cutterhead in the chart for your convenience.
Cutterhead Upgrades for Grizzly Machines
| Cutterhead Size | Byrd | Grizzly Spiral | Grizzly Helical | Grizzly V-Helical | Grizzly/Shop Fox Model |
|---|---|---|---|---|---|
| 6" | H7764 | H7653 | T27698 | T31849 | G0452 Series G1182 Series (since 2003) G0654 W1679 W1745 |
| T27699 | G0604/G0604X | ||||
| 8" | H7765 | H7654 | T32018 | G0500 G0586 G1018 W1684 |
|
| H8803 | T27697 | G0490/G0490X (does not fit G0490W/G0490XW) W1741/W1741S |
|||
| T23860 | T27713 | G0656/G0656P (does not fit G0656W/G0656XW) | |||
| 12" | H9291 | T27696 | G0609/G0609X W1744/W1744S |
||
| 15" | H7768 | H7655 | T27695 | T32020 | G0453 SERIES (excludes G0453W/G0453ZW) G0550 G0551 G1021 SERIES (Since 1995) W1692 W1723 W1724 W1742S |
| T27625 | G0453W/G0453ZW | ||||
| 20" | H7769 | H7656 | T27694 | T32021 | G0454 SERIES (excludes G0454W/G0454ZW) G1033 SERIES (since 1995) W1683 W1718 W1747 W1754/W1754S |
Compatible Cutterheads for Other Brands
| Cutterhead Size | 6" | 8" | 12" | 15" | 20" | |
| Byrd | H7764 | H7765 | H8803 | H9291 | H7768 | H7769 |
| Grizzly Spiral | H7653 | H7654 | H7655 | H7656 | ||
| Grizzly Helical | T27698 | T27697 | T27696 | T27695 | T27694 | |
| Grizzly V-Helical | T31849 | T32018 | T32020 | T32021 | ||
Compatible Models | ||||||
| Bridgewood | BW-6R | BW8J | BW15P | BW20P | ||
| Delta | DJ-20 | 22-675 22-780 22-785 22-790X 22-790X5 DC380 |
||||
| General | 80-100L 80-150L |
30-1H7655 30-125CE |
30-300 | |||
| Geetech | CT-200 CT-204L |
|||||
| Jet | JJ-60S JJ-6CSDX JJ-6CSX |
JJ-8CS | JJ-12 | JWP-15C | JWP-208 JW-208-1 |
|
| Oliver | 4255 | |||||
| Powermatic | 1791279DX-54A 1791279DXK-54A |
P1285 | 1791209 1791210-15S |
209 | ||
| Ridgid | JP0610 | |||||
| Sunhill | CT-60L SM-150 |
SM-204 | CT-382 CT-38B |
CT-508 | ||
| Woodtek | 855266 | 924083 | ||||
| Yorkcraft | YC-12J | |||||
Inserts
Below, you'll find which replacement inserts you need for your cutterhead. We've linked the inserts for your convenience.
| Cutterhead Size | 6" | 8" | 12" | 15" | 20" | |||||
| Brand | Cutterhead | Inserts | Cutterhead | Inserts | Cutterhead | Inserts | Cutterhead | Inserts | Cutterhead | Inserts |
| Byrd | H7764 | H7354 | H7765 | H7354 | H9291 | H7354 | H7768 | H7354 | H7769 | H7354 |
| H8803 | T27625 | |||||||||
| T23860 | ||||||||||
| Grizzly Spiral | H7653 | H7319 | H7654 | H7319 | H7655 | H7354 | H7656 | H7319 | ||
| Grizzly Helical | T27698 | H9893 | T27697 | H9893 | T27696 | H9893 | T27695 | H9893 | T27694 | H9893 |
| T27699 | T27713 | |||||||||
| Grizzly V-Helical | T31849 | T32018 | T32020 | T32021 | ||||||
